FRP Water Treatment Composite Tank High strength and light weight
Détails sur le produit:
| Place of Origin: | China |
| Nom de marque: | China brand |
| Certification: | CE/UL/NSF |
| Model Number: | 0818 |
| Documents: | FRP-tanks-print.pdf |
Conditions de paiement et expédition:
| Minimum Order Quantity: | 1 set |
|---|---|
| Prix: | négociable |
| Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized |
| Delivery Time: | 5-8 working days after payment received |
| Payment Terms: | T/T |
| Supply Ability: | 10,000 set per month |
|
Détail Infomation |
|||
| Product Size(inch): | 08x18 | Product Diam&Height(mm): | φ200×450 |
|---|---|---|---|
| Product Opening(inch): | Top Opening 2.5"Thread | Design Flow Rate(T/H): | 0.1～0.2 |
| Original: | China | Advantages: | High strength and light weight |
| Material: | FRP | Usage: | Water treatment |
Description de produit
FRP水处理复合材料 高强度,轻质
The FRP tank for water treatment is a corrosion-resistant composite pressure vessel formed in one go by four-dimensional winding with reinforced fiber and high-performance resin on the basis of PE or FRP liner, which can meet the different needs of various water treatment equipment. The whole tank body consists of upper and lower openings, tank body, discharge port and base. The upper and lower openings and discharge port are mostly connected by high-density and high-strength thread or flange. The base is generally made of FRP or reinforced PP.
Water treatment tanks are a type of equipment specifically used in water treatment processes. They have a variety of uses, including but not limited to clean water, pure water, softened water, and sewage. In addition, water treatment tanks are not only used for water treatment in industries such as industry, agriculture, chemicals, medicine, food processing, and winemaking, but are also suitable for home and commercial use. These devices can be selected according to different needs. Appropriate types and specifications to meet specific water treatment requirements.
|
尺寸(英寸) |
直径&高度(mm) |
开口(英寸) |
设计流量(T/ H ) |
|
0818 |
φ200×450 |
顶部开口2.5 英寸螺纹 |
0.1～0.2 |
|
0835 |
φ200×890 |
顶部开口2.5 英寸螺纹 |
0.2～0.4 |
|
0844 |
φ200×1100 |
顶部开口2.5 英寸螺纹 |
0.2～0.5 |
|
1035 |
φ250×890 |
顶部开口2.5 英寸螺纹 |
0.5～1.0 |
|
1054 |
φ250×1400 |
顶部开口2.5 英寸螺纹 |
0.5～1.5 |
|
1254 |
φ300×1400 |
顶部开口2.5 英寸螺纹 |
1.6～2.2 |
|
1265 |
φ300 ×1650 |
顶部开口2.5 英寸螺纹 |
2.0～2.5 |
|
1354 |
φ325 ×1400 |
顶部开口2.5 英寸螺纹 |
2.0～2.5 |
|
1365 |
φ325×1650 |
顶部开口2.5 英寸螺纹 |
2.0～2.5 |
|
1454 |
φ350×1400 |
顶部开口2.5 英寸螺纹 |
2.5～3.0 |
|
1465 |
φ350×1650 |
顶部开口2.5 英寸螺纹 |
2.5～3.0 |
|
1654 |
φ400×1400 |
顶部开口2.5 英寸螺纹 |
3.2～4.5 |
|
1665 |
φ400×1650 |
顶部开口2.5 英寸螺纹 |
3.2～4.5 |
|
2069 |
φ500×1750 |
顶部开口4英寸螺纹 |
4.5～6.0 |
|
2069 |
φ500×1750 |
顶部和底部开口 4” 螺纹 |
4.5～6.0 |
|
2474 |
φ600 ×1900 |
顶部开口4英寸螺纹 |
6.2～8.2 |
|
2474 |
φ600×1900 |
顶部和底部开口4英寸螺纹 |
6.2～8.2 |
|
3074 |
φ750×1900 |
顶部开口4英寸螺纹 |
7.2～12.2 |
|
3074 |
φ750×1900 |
顶部和底部开口4英寸螺纹 |
7.2～12.2 |
|
3674 |
φ900×1900 |
顶部开口4英寸螺纹 |
13.2～16.2 |
|
3674 |
φ900×1900 |
顶部和底部开口4英寸螺纹 |
13.2～16.2 |
|
3687 |
φ900×2200 |
顶部开口4英寸螺纹 |
13.2～16.2 |
|
3687 |
φ900×2200 |
顶部和底部开口4英寸螺纹 |
13.2～16.2 |
|
3696 |
φ900×2400 |
顶部和底部开口6英寸法兰 |
13.2～16.2 |
|
4074 |
φ1000×1900 |
顶部和底部开口4英寸螺纹 |
17.0～23.0 |
|
4074 |
φ1000×1900 |
顶部和底部开口4英寸螺纹 |
17.0～23.0 |
|
4087 |
φ1000×2200 |
顶部和底部开口4英寸螺纹 |
17.0～23.0 |
|
4096 |
φ1000×2400 |
顶部和底部开口6英寸法兰 |
18.0～25.0 |
|
4887 |
φ1200×2200 |
顶部和底部开口6英寸法兰 |
28.0～38.0 |
|
4896 |
φ1200×2400 |
顶部和底部开口6英寸法兰 |
28.0～38.0 |
|
6096 |
φ1500×2400 |
顶部和底部开口6英寸法兰 |
38.0～55.0 |
|
6396 |
φ1600×2400 |
顶部和底部开口6英寸法兰 |
38.0～55.0 |
|
7296 |
φ1800×2400 |
顶部和底部开口6英寸法兰 |
55.0～80.0 |
|
8096 |
φ2000×2400 |
顶部和底部开口6英寸法兰 |
80.0～100.0 |
|
80102 |
φ2000×2600 |
顶部和底部开口6英寸法兰 |
80.0～100.0 |
