DuPont XP 77 IG 8 Inch PVDF UF Membrane High-Performance Filtration for Critical Industries
Détails sur le produit:
| Lieu d'origine: | CHINE |
| Nom de marque: | Dupont |
| Certification: | CE |
| Numéro de modèle: | Integratec ™ XP 77 IG (anciennement SFP 2880XP) |
Conditions de paiement et expédition:
| Quantité de commande min: | 1 pc |
|---|---|
| Prix: | négociable |
| Détails d'emballage: | Emballage d'exportation standard |
| Délai de livraison: | 5- 8 jours de travail |
| Conditions de paiement: | T / t |
| Capacité d'approvisionnement: | 60000 unités par mois |
|
Détail Infomation |
|||
| XP 77 Ig Diamètre: | 8 pouces | XP 77 IG Surface de membrane de XP 77 IG: | 77 m² |
|---|---|---|---|
| XP 77 IG Matériau: | PVDF | Plage de débit par module: | 2.0 ️ 8,5 m3/h |
| Diamètre des pores nominaux de XP 77 IG: | 0,03 µm | Pression de fonctionnement de xp 77 ig: | 1-5 bar |
| Max. opération TMP de ce module: | 2.1 bar | MAX OPERating Air Racon Flow de ce module: | 12 nm3 / h |
| Naocl (max.) De ce module: | 2 000 mg / L | Certifications de ce modèle: | ISO 9001, NSF, CE |
| Application: | Pharma et boisson | Avantages du modèle: | Solutions de filtration haute performance |
| Souligner: | Membrane DuPont XP 77 UF, membrane PVDF 8 pouces, membrane UF pharmaceutique | ||
Description de produit
The DuPont XP 77 IG 8 Inch PVDF UF Membrane is a state-of-the-art ultrafiltration solution designed for high-stakes applications in pharmaceuticals, beverages, and industrial water treatment. Crafted by DuPont Water Solutions, this 8-inch membrane features premium polyvinylidene fluoride (PVDF) material, renowned for its exceptional chemical resistance, mechanical strength, and thermal stability—making it a reliable choice for environments demanding uncompromising purity and long-term performance. As a key offering in DuPont’s IntegraTec™ lineup, the DuPont XP 77 IG 8 Inch PVDF UF Membrane sets benchmarks in precision filtration, effectively removing particles, colloids, and microorganisms while maintaining consistent flux rates.
The membrane operates on an outside-in filtration工艺: feed water flows across the outer surface of the hollow fibers, where contaminants as small as 0.03 µm are retained. Purified filtrate then passes through the fiber lumen, ensuring efficient separation without the need for chemical coagulants. Its innovative design allows for easy backwashing and cleaning, minimizing fouling and extending service life—reducing operational downtime and maintenance costs.
Key Specifications of DuPont XP 77 IG 8 Inch PVDF UF Membrane
|
Attribute |
Value |
|
Membrane Material |
Polyvinylidene Fluoride (PVDF) |
|
Diameter |
8 Inch |
|
Effective Membrane Area |
77 m² (829 sq ft) |
|
Max Operating Pressure |
5.0 bar (72.5 psi) |
|
Operating Temperature Range |
1–40°C (34–104°F) |
|
pH Range (Operating) |
2–11 |
|
Nominal Pore Size |
0.03 µm |
The DuPont XP 77 IG 8 Inch PVDF UF Membrane offers standout advantages: 99.99% microorganism removal ensures compliance with pharmaceutical and beverage safety standards; PVDF construction resists harsh cleaning agents, prolonging membrane life; and high flux rates optimize water production efficiency. It is widely used in pharmaceutical water purification, beverage clarification, industrial wastewater reuse, and RO pretreatment. Backed by DuPont’s global technical support, this membrane delivers a cost-effective, sustainable solution for industries prioritizing purity and reliability.
