1,000 m³/day BWC1000 – Modular Dual‑Container BWRO Flexible Regional Water Security Desal
Détails sur le produit:
| Lieu d'origine: | CHINE |
| Nom de marque: | FG Water Technologies |
| Certification: | CE |
| Numéro de modèle: | BWC1000 |
Conditions de paiement et expédition:
| Quantité de commande min: | 1 |
|---|---|
| Détails d'emballage: | Standard |
| Délai de livraison: | 30 jours ouvrables |
| Conditions de paiement: | T/T |
|
Détail Infomation |
|||
| Taux de récupération évalué: | 70% | Flux de produits évalué: | 42 m³/h |
|---|---|---|---|
| Quantité de membrane RO: | 50 pièces | Taille du conteneur: | 40 + 40 pieds |
| Puissance nominale: | 64,4 kW | Consommation d'énergie: | 1,06 kWh/m³ |
Description de produit
1,000 m³/day BWC1000 – Modular Dual‑Container BWRO Flexible Regional Water Security Desal
The BWC1000 breaks the single‑container limit with a two‑container (40 ft + 40 ft) modular design that simplifies logistics and staging. One container houses pre‑treatment and filtration, the other the RO banks and high‑pressure pumps – together they produce 42 m³/h (1,000 m³/day). This separation allows independent servicing and future upgrades. With 50 RO membranes and an energy consumption of 1.06 kWh/m³, the BWC1000 offers a dependable, scalable supply for regional water authorities, industrial parks, and large agricultural zones.
Key Specifications
| Parameter | Unit | Value |
|---|---|---|
| Rated Product Flow | m³/h | 42 |
| L/s | 11.67 | |
| Rated Recovery Rate | % | 70 |
| Rated Feed Flow | m³/h | 60 |
| Max System Pressure | barg | 20 |
| RO Membrane Spec | inch | 8,010* |
| RO Membrane Qty | pcs | 50 |
| Dry Weight | ton | 16 |
| Container Size | ft | 40 + 40 |
| Rated Power | kW | 64.4 |
| Energy Consumption | kWh/m³ | 1.06 |
| Installed Power | kW | 103.2 |
| Power Input | – | 3PH, 380V ±10%, 50Hz |
*Note: membrane spec per original datasheet; confirm with manufacturer for latest.
System Features
-
Twin‑container modularity – enables staged installation and easier transport.
-
Independent pre‑treatment – simplifies chemical dosing and backwash operations.
-
Integrated energy recovery – reduces pump load and extends component life.
-
IoT ready – optional sensors for predictive maintenance and operational consulting.
Applications:
Regional water grids, industrial estates, large mining camps, major resort complexes.
Regional water grids, industrial estates, large mining camps, major resort complexes.
